ACR Straight Tubes
Rigid, high-cleanliness copper pipes ideal for plumbing, gas pipelines, and heating plants.
Every dispatch includes official EN 10204 3.1 chemical analysis certificates and physical wall load/eddy-current testing documentation.
Product Overview
ACR Straight Tubes are rigid copper pipes manufactured to maintain extreme structural straightness and absolute interior hygiene. Ends are plugged with airtight caps immediately after production to prevent debris contamination.
Technical Specifications
| Alloy Grade | Cu-DHP / Cu-ETP (Purity 99.9%) |
| Standard Temper | Hard Drawn (H80) / Half-Hard (H58) |
| Outer Diameter | 3/8" to 4-1/8" (9.52 mm to 104.78 mm) |
| Wall Thickness | 0.035" to 0.120" (0.89 mm to 3.05 mm) |
| Length Range | 3.0 meters to 6.0 meters |
Industrial Applications
Medical gas pipelines, vacuum supply systems, central heating distribution networks, steam lines, domestic water plumbing, and heavy-duty HVAC piping.
Dimensions & Geometry
Available in standard lengths of 3.0m, 5.8m (for optimal loading into 20ft containers), and 6.0m. Custom wall profiles are available for high-pressure systems.
Packaging Specifications
Bundled with heavy steel strapping, protected by end-caps, and nested in heavy-duty long wooden crates to prevent bending and surface scratches.
Verified Certifications
Certified compliant with ASTM B88, ASTM B819 (Medical Gas), and EN 1057 European plumbing standards.
Global Export & Incoterms
Exported under strict customs clearance on FOB Tashkent, CIF Riga, CIF Hamburg, and CIF Alexandria.
